XCB-L

Type Up-Style Conveyor Belt

Usage: apply to convey materials for plastic granulators.

Features
·Integral sheet metal forming, steel is strong and difficult to deform;
·European-style design, reliable, durable and long life;
·Moving flexibly, highly can adjust;
·Achieved with other planar conveyor belts connected to use;
·Easy to install, adjust and operate.

Product Parameters

We can design and develop according to the needs of our customers to meet the requirements of different clients.

Model A
(mm)
B
(mm)
C
(mm)
D
(mm)
E
(mm)
F
(mm)
G
(mm)
H
(mm)
I
(mm)
L
(mm)
M
(mm)
N
(mm)
Power
(W)
Weight
(kg)
Power
XCB/1 700  1300  250  354  360  470  915+65 257+65 365+65 1810  505  845  400  92  380V/50HZ/3Ø
220V/60HZ/3Ø
XCB/2 700  1300  350  454  460  570  915+65 257+65 365+65 1810  505  845  400  102
XCB/3 700  1300  450  554  560  670  915+65 257+65 365+65 1810  505  845  400  112
XCB/4 700  1800  250  354  360  470  1130+135 192+135 300+135 2230  650  910  400  100
XCB/5 700  1800  350  454  460  570  1130+135 192+135 300+135 2230  650  910  400  110
XCB/6 700  1800  450  554  560  670  1130+135 192+135 300+135 2230  650  910  400  120
